TMS5700432APZQQ1的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | ARM Microcontrollers - MCU |
| RoHS： | No |
| Core： | ARM Cortex R4 |
| Data Bus Width： | 16 bit/32 bit |
| Maximum Clock Frequency： | 80 MHz |
| Program Memory Size： | 384 kB |
| Data RAM Size： | 32 kB |
| On-Chip ADC： | Yes |
| Operating Supply Voltage： | 1.2 V, 3.3 V |
| Maximum Operating Temperature： | + 125 C |
| Package / Case： | LQFP-100 |
| Mounting Style： | SMD/SMT |
| A/D Bit Size： | 12 bit |
| A/D Channels Available： | 16 |
| Brand： | Texas Instruments |
| Data RAM Type： | SRAM |
| Data ROM Size： | 16 kB |
| Data ROM Type： | EEPROM |
| Development Kit： | LAUNCHXL-TMS57004 |
| Interface Type： | CAN, LIN, MibSPI, SCI, SPI, UART, USART |
| Minimum Operating Temperature： | - 40 C |
| Number of Programmable I/Os： | 45 |
| Processor Series： | TMS5700432 |
| Program Memory Type： | Flash |
| Series： | TMS570LS0432 |
TMS5700432APZQQ1相关文档
- Evaluation Kits: Hercules TMS570LS04x/03x LaunchPad Evaluation Kit
- Evaluation Kits: XDS200 Price/Performance-balanced Debug Probe
- Evaluation Kits: TMS570LS04x/03x Hercules Development Kit
- Evaluation Kits: SafeTI? Hitex Safety Kit - TMS570LS31x/21x
- Evaluation Kits: TMS570LS31x Hercules USB Stick Development Kit
- Evaluation Kits: XDS560 High Performance Debug Probe
- Evaluation Kits: XDS100 Low-cost Debug Probe
- Function Diagram: fbd_spns186a
TMS5700432APZQQ1应用笔记
- Verification of Data Integrity Using CRC
- Important ARM Ltd Application Notes for TI Hercules ARM Safety MCUs
- UART Bootloader for Hercules TMS570LS04X MCU
- Execution Time Measurement for Hercules ARM Safety MCUs (Rev. A)
- Initialization of Hercules ARM Cortex-R4F Microcontrollers (Rev. D)
- Comp Cons: Mig from 570LS31x/21x or 570LS12x/11x to 570LS04/03x Safety MCUs
- Basic PBIST Configuration and Influence on Current Consumption (Rev. C)
- Leveraging the High-End Timer Transfer Unit on Hercules ARM Safety MCUs (Rev. A)
- Configuring a CAN Node on Hercules ARM Safety MCUs
- CAN Bus Bootloader for TMS570LS04X MCU
- Use of All 1'?s and All 0's Valid in Flash EEPROM Emulation
- Generating Operating System Tick Using RTI on a Hercules ARM Safety MCU
- NHET Getting Started (Rev. B)
- ADC Source Impedance for Hercules ARM Safety MCUs (Rev. B)
- Hercules Family Frequency Slewing to Reduce Voltage and Current Transients
- Interfacing TPS65381 With Hercules Microcontrollers (Rev. A)
- Initialization of the TMS570LS043x, 570LS033x & RM42L432 Hercules ARM Cortex-R4
- Configuring the Hercules ARM Safety MCU SCI/LIN Module for UART Communication (Rev. A)
- Usage of MPU Subregions on TI Hercules ARM Safety MCUs
- SPI Bootloader for Hercules TMS570LS04X MCU
- FlexRay Transfer Unit (FTU) Setup
- 3.3 V I/O Considerations for Hercules Safety MCUs (Rev. A)
