Toshiba Semiconductor and Storage
TPN7R506NH,L1Q的详细信息
| Datasheets： | |
|---|---|
| TPN7R506NH： | |
| Product Photos： | |
| 8-PowerVDFN： | |
| 8-PowerVDFN,-8-TSON： | |
| Standard Package ： | 5,000 |
| Category： | Discrete Semiconductor Products |
| Family： | FETs - Single |
| Series： | - |
| Packaging ： | Tape & Reel (TR) |
| FET Type： | MOSFET N-Channel, Metal Oxide |
| FET Feature： | Standard |
| Drain to Source Voltage (Vdss)： | 60V |
| Current - Continuous Drain (Id) @ 25°C： | 26A (Tc) |
| Rds On (Max) @ Id, Vgs： | 7.5 mOhm @ 13A, 10V |
| Vgs(th) (Max) @ Id： | 4V @ 200µA |
| Gate Charge (Qg) @ Vgs： | 22nC @ 10V |
| Input Capacitance (Ciss) @ Vds： | 1800pF @ 30V |
| Power - Max： | 42W |
| Mounting Type： | Surface Mount |
| Package / Case： | 8-PowerVDFN |
| Supplier Device Package： | 8-TSON Advance |
| Dynamic Catalog： | N-Channel Standard FETs |
| Other Names： | TPN7R506NH,L1Q(MTPN7R506NHL1QTR |
