Texas Instruments
TPS28225DR的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Gate Drivers |
| RoHS： | Yes |
| Brand： | Texas Instruments |
| Configuration： | Single |
| Number of Drivers： | 2 |
| Rise Time： | 10 ns |
| Fall Time： | 5 ns |
| Output Current： | 6 A |
| Supply Voltage - Max： | 8.8 V |
| Supply Voltage - Min： | 4 V |
| Supply Current： | 0.5 mA |
| Maximum Power Dissipation： | 1250 mW |
| Maximum Operating Temperature： | + 125 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | SOIC-8 |
| Type： | High Side/Low Side |
| Minimum Operating Temperature： | - 40 C |
| Number of Outputs： | 2 |
| Packaging： | Reel |
| Series： | TPS28225 |
| Factory Pack Quantity： | 2500 |
| Unit Weight： | 72.600 mg |
TPS28225DR相关文档
- Evaluation Kits: 36Vdc-75Vdc Input, 20V @ 4A Output, Active Clamp Forward
- TINA Reference Design: TPS28225 TINA-TI Transient Reference Design
- Evaluation Kits: 36Vdc-75Vdc Input, 6V @ 20A Output, Active Clamp Forward
- Evaluation Kits: 18Vdc-54Vdc Input, 24V @ 5A Output, Active Clamp Forward
- SPICE Model: TPS28225 PSpice Transient Model
- SPICE Model: TPS28225 TINA-TI Transient Spice Model
- Evaluation Kits: 48V Input 3.3V/30A with Output Pre-bias
- Function Diagram: alt_slus710c
