| 型号： | TSC2005IYZLT |
| 厂商： |
 Texas Instruments |
| 标准： |   |
| 分类： | 半导体 ， 集成电路 - IC |
| 描述： | touch screen converters & controllers nano-power touch screen controller |
| 报错 收藏 赞 | |
Datasheet下载地址
| 本地下载 >> 厂商下载2 >> 第三方平台下载 >> |
TSC2005IYZLT的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Touch Screen Converters & Controllers |
| RoHS： | Yes |
| Brand： | Texas Instruments |
| Type： | Resistive Touch Controllers |
| Input Type： | 1 TSC |
| Data Rate： | 50 SPS |
| Resolution： | 10 bit, 12 bit |
| Interface Type： | 4-Wire, SPI |
| Supply Voltage： | 1.6 V to 3.6 V |
| Supply Current： | 383 uA |
| Operating Temperature： | - 40 C to + 85 C |
| Package / Case： | DSBGA-28 |
| Maximum Operating Temperature： | + 85 C |
| Minimum Operating Temperature： | - 40 C |
| Mounting Style： | SMD/SMT |
| Packaging： | Reel |
| Series： | TSC2005 |
| Factory Pack Quantity： | 250 |
| Supply Voltage - Max： | 3.6 V |
| Supply Voltage - Min： | 1.6 V |
TSC2005IYZLT应用笔记
- TSC2005 Power Consumption Under Different Modes
- TSC2005/6 Linux® Drivers
- Apply TI TSC for Various and Multiple Functions
- PCB Layout Guideline for TI Resistive TSC Devices
- Calibration in touch-screen systems
- Q4 2007 Issue Analog Applications Journal
- POR and Resets in TSC2004/5/6
- Set Up and Use TSC Timings
- Important Considerations to Assure a Safe POR
- Q3 2007 Issue Analog Applications Journal
- Reducing Analog Input Noise in Touch Screen Systems (Rev. A)
- Operation Schemes of Touch Screen Controllers
- Q4 2007 Issue Analog Applications Journal (Rev. A)
