UCC27537DBVT的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Gate Drivers |
| RoHS： | Yes |
| Product： | MOSFET Gate Drivers |
| Configuration： | Single, Non-Inverting |
| Number of Drivers： | 1 |
| Rise Time： | 15 ns |
| Fall Time： | 8 ns |
| Output Current： | 5 A |
| Supply Voltage - Max： | 35 V |
| Supply Voltage - Min： | 10 V |
| Supply Current： | 2.5 A, 5 A |
| Maximum Operating Temperature： | + 140 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | SOT-23-5 |
| Type： | FET and IGBT Single-Gate Driver |
| Brand： | Texas Instruments |
| Maximum Turn-Off Delay Time： | 26 ns |
| Maximum Turn-On Delay Time： | 26 ns |
| Minimum Operating Temperature： | - 40 C |
| Number of Outputs： | 1 |
| Packaging： | Reel |
| Series： | UCC27537 |
| Factory Pack Quantity： | 250 |
UCC27537DBVT相关文档
- Evaluation Kits: UCC27531 Evaluation Module
- SPICE Model: UCC27537 PSpice Transient Model
- Evaluation Kits: Gate Driver daughter card with isolation based on UCC27532
