UCC28700DBVR的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | AC/DC Converters |
| RoHS： | Yes |
| Brand： | Texas Instruments |
| Output Voltage： | 14 V |
| Input / Supply Voltage - Min： | 9 V |
| Input / Supply Voltage - Max： | 35 V |
| Duty Cycle - Max： | 99 % |
| Switching Frequency： | 875 Hz to 140 kHz |
| Supply Current： | 2.1 mA |
| Operating Temperature Range： | - 20 C to + 125 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | SOT-23-6 |
| Packaging： | Reel |
| Development Kit： | UCC28700EVM-068 |
| Isolation： | Isolated |
| Number of Outputs： | 1 Output |
| Output Current： | 25 mA |
| Series： | UCC28700 |
| Factory Pack Quantity： | 3000 |
| Topology： | Flyback |
| Type： | Current Mode PWM Controllers |
UCC28700DBVR相关文档
- Evaluation Kits: 85VAC-265VAC Input, 5V@4A Dual Port Charger For Tablets and Smart Phones
- Evaluation Kits: UCC28700 Evaluation Module
- Evaluation Kits: UCC28720EVM-212 5W Evaluation Module for USB off-line adapter
- Evaluation Kits: 8W Primary-Side Regulated Flyback using UCC28700
- Evaluation Kits: UCC28711 Evaluation Module
- Function Diagram: alt_slusb41
