型号：	UCC2897APW
厂商：	Texas Instruments
标准：
分类：	半导体，集成电路 - IC
描述：	switching controllers adv crnt-mode active clamp pwm controller
PDF：	预览
报错收藏赞

Datasheet下载地址

本地下载 >> 厂商下载2 >> 第三方平台下载 >>

UCC2897APW的详细信息

Manufacturer：	Texas Instruments
Product Category：	Switching Controllers
RoHS：	Yes
Brand：	Texas Instruments
Topology：	Flyback, Forward
Number of Outputs：	1
Switching Frequency：	1000 kHz
Duty Cycle - Max：	74 %
Output Voltage：	3 V
Output Current：	2000 mA
Maximum Operating Temperature：	+ 125 C
Mounting Style：	SMD/SMT
Package / Case：	TSSOP-20
Packaging：	Tube
Development Kit：	UCC2897AEVM
Fall Time：	14 ns
Minimum Operating Temperature：	- 40 C
Operating Supply Voltage：	12 V
Rise Time：	19 ns
Series：	UCC2897A
Factory Pack Quantity：	70
Unit Weight：	77 mg
