Fairchild Semiconductor
UF4007的详细信息
| Manufacturer： | Fairchild Semiconductor |
|---|---|
| Product Category： | Rectifiers |
| RoHS： | Yes |
| Product： | Ultra Fast Recovery Rectifiers |
| Configuration： | Single |
| Reverse Voltage： | 1000 V |
| Forward Voltage Drop： | 1.7 V |
| Recovery Time： | 75 ns |
| Forward Continuous Current： | 1 A |
| Max Surge Current： | 30 A |
| Reverse Current IR： | 10 uA |
| Mounting Style： | Through Hole |
| Package / Case： | DO-41 |
| Packaging： | Reel |
| Brand： | Fairchild Semiconductor |
| Maximum Operating Temperature： | + 150 C |
| Minimum Operating Temperature： | - 65 C |
| Power Dissipation： | 2.08 W |
| Series： | UF4007 |
| Factory Pack Quantity： | 5000 |
| Part # Aliases： | UF4007_NL |
| Unit Weight： | 245 mg |
UF4007相关文档
- Application Note: AN-4138: Design Considerations for Battery Charger Using Green Mode Fairchild Power Switch (FPS™)
- Application Note: AN-6014: Green Current Mode PWM Controller FAN7602
- Application Note: AN-4146: Design Guidelines for Quasi-Resonant Converters Using FSCQ-Series Fairchild Power Switch (FPS™)
- PCN: Fairchild Semiconductor - PCN 6-4-10
