UNR521400L的详细信息
| Datasheets： | |
|---|---|
| UNR521400L View All Specifications： | |
| Product Photos： | |
| SMINI3-F1： | |
| Catalog Drawings： | |
| PNP, NPN S-Mini Type： | |
| Standard Package ： | 3,000 |
| Category： | Discrete Semiconductor Products |
| Family： | Transistors (BJT) - Single, Pre-Biased |
| Series： | - |
| Packaging ： | Tape & Reel (TR) |
| Transistor Type： | NPN - Pre-Biased |
| Current - Collector (Ic) (Max)： | 100mA |
| Voltage - Collector Emitter Breakdown (Max)： | 50V |
| Resistor - Base (R1) (Ohms)： | 10k |
| Resistor - Emitter Base (R2) (Ohms)： | 47k |
| DC Current Gain (hFE) (Min) @ Ic, Vce： | 80 @ 5mA, 10V |
| Vce Saturation (Max) @ Ib, Ic： | 250mV @ 300µA, 10mA |
| Current - Collector Cutoff (Max)： | 500nA |
| Frequency - Transition： | 150MHz |
| Power - Max： | 150mW |
| Mounting Type： | Surface Mount |
| Package / Case： | SC-70, SOT-323 |
| Supplier Device Package： | SMini3-G1 |
| Other Names： | UN5214-(TX)UN5214-TXUN5214TRUN5214TR-NDUNR521400LTRUNR524100L |
