XP Power
VEP15US09的详细信息
| Datasheets： | |
|---|---|
| VEP Series, 8-36 W： | |
| Product Photos： | |
| VEP08-15： | |
| Other Related Documents： | |
| VEP Series TUV Certificate： | |
| VEP Series UL Certificate： | |
| VEP Series CB Report： | |
| Product Training Modules： | |
| IEC 60601 3rd Edition Medical Safeties： | |
| RoHS Information： | |
| VEP Series Declaration of Conformity： | |
| Standard Package ： | 5 |
| Category： | Power Supplies - External/Internal (Off-Board) |
| Family： | AC DC Desktop, Wall Adapters |
| Series： | VEP |
| Region Utilized： | International |
| Form： | Wall Mount |
| Input Type： | Multi-Blade (Sold Separately) |
| Voltage - Input： | 80 ~ 264 VAC |
| Voltage - Output： | 9V |
| Current - Output (Max)： | 1.4A |
| Power (Watts)： | 15W |
| No Load Power Consumption： | 300mW (Max) |
| Polarization： | Positive Center |
| Applications： | ITE (Commercial), Medical |
| Efficiency： | 80% |
| Operating Temperature： | 0°C~ 40°C |
| Output Connector： | Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 11.0mm |
| Size / Dimension： | 2.95" L x 1.81" W x 1.20" H (75.0mm x 46.0mm x 30.5mm) |
| Approvals： | - |
| Power (Watts) - Max： | 13W |
| Input Connector： | Multi-Blade |
| Cord Length： | 70.9" (1.80m) |
| Weight： | 0.265 lb (120.2g) |
| Dynamic Catalog： | VEP Series |
| Associated Product： | 1470-2327-ND - VEP US AC INPUT PLUG1470-2326-ND - VEP UK AC INPUT PLUG1470-2325-ND - VEP EU AC INPUT PLUGVEP PLUG CN-ND - VEP CHINA AC INPUT PLUGVEP PLUG AU-ND - VEP AUSTRALIAN AC INPUT PLUG |
| Other Names： | 1470-2332 |
