VS-ST110S14P0的详细信息
| Datasheets： | |
|---|---|
| VS-ST110SPBF Series： | |
| Product Photos： | |
| TO-209AC TO-94 PKG： | |
| Standard Package ： | 25 |
| Category： | Discrete Semiconductor Products |
| Family： | SCRs - Single |
| Series： | - |
| Packaging ： | Bulk |
| Voltage - Off State： | 1400V |
| Voltage - Gate Trigger (Vgt) (Max)： | 3V |
| Current - Gate Trigger (Igt) (Max)： | 150mA |
| Voltage - On State (Vtm) (Max)： | 1.52V |
| Current - On State (It (AV)) (Max)： | 110A |
| Current - On State (It (RMS)) (Max)： | 175A |
| Current - Hold (Ih) (Max)： | 600mA |
| Current - Off State (Max)： | 20mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm)： | 2700A, 2830A |
| SCR Type： | Standard Recovery |
| Operating Temperature： | -40°C ~ 125°C |
| Mounting Type： | Chassis, Stud Mount |
| Package / Case： | TO-209AC, TO-94-4, Stud |
| Supplier Device Package： | TO-209AC (TO-94) |
| Other Names： | *ST110S14P0ST110S14P0ST110S14P0-NDVSST110S14P0VSST110S14P0-ND |
