103635-8的详细信息
| Datasheets： | |
|---|---|
| 103635 Drawing： | |
| Product Photos： | |
| 103906-8, 103635-8, 5-103635-8, 5-104935-9： | |
| RoHS Information： | |
| 103635-8 Statement of Compliance： | |
| Catalog Drawings： | |
| Latching Single without Holddown： | |
| Featured Product： | |
| AMPMODU Connectors ： | |
| 3D Model： | |
| 103635-8.pdf： | |
| Standard Package ： | 1,512 |
| Category： | Connectors, Interconnects |
| Family： | Rectangular Connectors - Headers, Male Pins |
| Series： | AMPMODU MTE, AMP |
| Packaging ： | Tube |
| Contact Type： | Male Pin |
| Connector Type： | Header, Shrouded |
| Number of Positions： | 9 |
| Number of Positions Loaded： | All |
| Pitch： | 0.100" (2.54mm) |
| Number of Rows： | 1 |
| Row Spacing： | - |
| Contact Mating Length： | 0.230" (5.84mm) |
| Mounting Type： | Through Hole, Right Angle |
| Termination： | Solder |
| Fastening Type： | - |
| Features： | - |
| Contact Finish： | Gold |
| Contact Finish Thickness： | 15µin (0.38µm) |
| Color： | Black |
| Mating Products： | A34206-ND - CONN RECPT 9POS .100 POLAR TINA34205-ND - CONN RECPT 9POS .100 POLAR 15AUA34204-ND - CONN RECPT 9POS .100 POLAR 30AU5-103959-8-ND - CONN RECEPT 9POS .100 26-30 TIN103648-8-ND - CONN RECEPT 9POS .100 UNLOADED103969-8-ND - CONN RECPT 9POS .100 22-26 15AU103959-8-ND - CONN RECEPT 9POS .100 26-30 TIN103960-8-ND - CONN RCPT 9POS .100 26-30 15GOLD103961-8-ND - CONN RCPT 9POS .100 26-30 30GOLDA28420-ND - CONN RECPT 9POS .100 POLAR TINA28419-ND - CONN RECPT 9POS .100 POLAR 15AUA28418-ND - CONN RECPT 9POS .100 POLAR 30AUA28421-ND - CONN RECPT 9POS .1" POL UNLOAD487526-8-ND - CONN RCPT 9POS.100 SLIM W/LATCH1-88859-3-ND - 009 HOUSING FFC RCPT SR 100CL487378-8-ND - CONN RECEPT 9POS .100 SLIMLINE |
| Other Names： | 103635-8-NDA28640 |
