| Datasheets： |
|
| 170328 Drawing： |
|
| 3-Pos. Positive Lock Triac Connector： |
|
| Product Photos： |
|
| 170334-1： |
|
| RoHS Information： |
|
| 170328-1 Statement of Compliance： |
|
| RoHS 2 Statement： |
|
| 3D Model： |
|
| 170328-1.pdf： |
|
| Standard Package ： |
3,500 |
| Category： |
Connectors, Interconnects |
| Family： |
Terminals - Quick Connects, Quick Disconnect Connectors |
| Series： |
Mark II, AMP |
| Packaging ： |
Tape & Reel (TR) |
| Terminal Type： |
Standard |
| Gender： |
Female |
| Tab Width： |
0.250" (6.35mm) |
| Tab Thickness： |
0.032" (0.81mm) |
| Tab Length： |
0.307" (7.80mm) |
| Length - Overall： |
1.016" (25.80mm) |
| Termination： |
Crimp |
| Wire Gauge： |
14-18 AWG |
| Insulation： |
Non-Insulated |
| Mounting Type： |
Free Hanging (In-Line) |
| Features： |
- |
| Color： |
- |
| Contact Material： |
Brass |
| Contact Finish： |
Tin |
| Insulation Diameter： |
0.087" ~ 0.134" (2.21mm ~ 3.40mm) |
| Dynamic Catalog： |
Mark II Series |
| For Use With： |
A107714-ND - CONN PLUG POSITIVE LOCKA113859-ND - CONN RCPT HSG 1POS .250 BLACK521120-5-ND - CONN RCPT HSG 1POS .250 REDA113858-ND - CONN RCPT HSG 1POS .250 BLUEA113856-ND - CONN RCPT HSG 2POS .250 BLUE190816-9-ND - CONN RCPT HSG 1POS .250 BLACK178833-1-ND - CONN RCPT HSG 2POS .250 NATURALA112764-ND - CONN RCPT HSG 1POS .250 NATURAL2-172410-1-ND - CONN RCPT HSG 3POS .187 NATURAL2-172076-6-ND - CONN RCPT HSG 1POS .250 BLUE2-172076-2-ND - CONN RCPT HSG 1POS .250 BLACK172076-7-ND - CONN RCPT HSG 1POS .250 RED172076-5-ND - CONN RCPT HSG 1POS .250 GREEN172076-4-ND - CONN RCPT HSG 1POS .250 YELLOW172076-2-ND - CONN PLUG HSNG 1POS STR .250 BLKA106309-ND - CONN RCPT HOUSING 1POS .250 TAB172410-1-ND - CONN RCPT HOUSING STR 3POS .250 |
| Associated Product： |
A120175-ND - TOOL EXTRACT FOR POSITIVE .250 |
| Other Names： |
170328-1-ND1703281A107096TR |
