31-10-RFX的详细信息
| Datasheets： | |
|---|---|
| 31-10-RFX Drawing： | |
| BNC Bulkhead Receptacles： | |
| Product Photos： | |
| 31-10-RFX： | |
| Catalog Drawings： | |
| 31-10 Bulkhead Mounting Hole： | |
| Standard Package ： | 1 |
| Category： | Connectors, Interconnects |
| Family： | Coaxial Connectors (RF) |
| Series： | - |
| Packaging ： | Bulk |
| Connector Style： | BNC |
| Connector Type： | Jack, Female Socket |
| Contact Termination： | Solder Cup |
| Shield Termination： | Solder |
| Impedance： | 50 Ohm |
| Mounting Type： | Panel Mount, Bulkhead - Rear Side Nut |
| Cable Group： | - |
| Fastening Type： | Bayonet Lock |
| Frequency - Max： | 4GHz |
| Features： | Board Lock |
| Housing Color： | White |
| Ingress Protection： | - |
| Body Material： | Brass |
| Body Finish： | Nickel |
| Center Contact Material： | Phosphor Bronze |
| Center Contact Plating： | Silver |
| Dielectric Material： | Polyamide (PA), Nylon |
| Voltage Rating： | 500V |
| Operating Temperature： | -55°C ~ 85°C |
| Dynamic Catalog： | BNC, RFX |
| Associated Product： | ARF1697-ND - CONN CAP COVER FOR BNC RFX JACKSARF1068-ND - CONN GROUND LUG FOR BNC RFX JACK |
| Other Names： | 031-10-RFX3110RFXARFX1063 |
