ITT Cannon, LLC
CA3102E28-12PB的详细信息
| Datasheets： | |
|---|---|
| CA3102E28-12P-B Drawing： | |
| Standard Package ： | 1 |
| Category： | Connectors, Interconnects |
| Family： | Circular Connectors |
| Series： | MIL-DTL-5015, CA-B |
| Packaging ： | Bulk |
| Connector Type： | Receptacle, Male Pins |
| Number of Positions： | 26 |
| Shell Size - Insert： | 28-12 |
| Shell Size, MIL： | - |
| Mounting Type： | Panel Mount, Flange |
| Termination： | Solder Cup |
| Fastening Type： | Reverse Bayonet Lock |
| Orientation： | N (Normal) |
| Ingress Protection： | IP67 - Dust Tight, Waterproof |
| Shell Material, Finish： | Aluminum Alloy, Olive Drab Cadmium Plated |
| Contact Finish： | Silver |
| Features： | - |
| Contact Finish Thickness： | - |
| Current Rating： | 22A |
| Voltage - Rated： | 500VAC, 700VDC |
| Operating Temperature： | -55°C ~ 125°C |
| Mating Products： | CA3106F28-12SB01-ND - CONN PLUG 26POS INLINE W/SKTSICA3106E28-12SB03-ND - CONN PLUG 26POS INLINE W/SKTSICA3106E28-12SB02-ND - CONN PLUG 26POS INLINE W/SKTSICA3108E28-12SBF80-ND - CONN PLUG 26POS RT ANG W/SKTSICA3106E28-12SB06-ND - CONN PLUG 26POS INLINE W/SKTSICA3108E28-12SB-ND - CONN PLUG 26POS RT ANG W/SKTSICA3108R28-12SBF80-ND - CONN PLUG 26POS RT ANG W/SKTSICA3108F28-12SBF80-ND - CONN PLUG 26POS RT ANG W/SKTSICA3106F28-12SBF80-ND - CONN PLUG 26POS INLINE W/SKTSICA3108F28-12SB-ND - CONN PLUG 26POS RT ANG W/SKTSICA3106E28-12SBF80-ND - CONN PLUG 26POS INLINE W/SKTSICA3106E28-12SB01-ND - CONN PLUG 26POS INLINE W/SKTSICA3106F28-12SB-ND - CONN PLUG 26POS INLINE W/SKTSICA3108E28-12SBF80F0-ND - CONN HSG R/A INLINE PLUG 26POSICA3106E28-12SB-ND - CONN PLUG 26POS INLINE W/SKTSICA3106E28-12SBF80F0-ND - CONN HSG INLINE MNT PLUG 26POS |
| Other Names： | CA3102E2812PBICA3102E28-12PB |
