EHF-120-01-L-D-SM的详细信息
| Datasheets： | |
|---|---|
| EHF Footprint： | |
| EHF-1xx-01-xx-D-xx-xx-xx Drawing： | |
| SHF,ESHF,EHF,ECF Spec Sheet： | |
| Product Photos： | |
| EHF-120-01-L-D-SM： | |
| Product Training Modules： | |
| Board-to-Board Connectors： | |
| Catalog Drawings： | |
| EHF Series SMT Side： | |
| Standard Package ： | 1 |
| Category： | Connectors, Interconnects |
| Family： | Rectangular Connectors - Headers, Male Pins |
| Series： | EHF |
| Packaging ： | Tube |
| Contact Type： | Male Pin |
| Connector Type： | Header, Shrouded |
| Number of Positions： | 40 |
| Number of Positions Loaded： | All |
| Pitch： | 0.050" (1.27mm) |
| Number of Rows： | 2 |
| Row Spacing： | 0.050" (1.27mm) |
| Contact Mating Length： | 0.120" (3.05mm) |
| Mounting Type： | Surface Mount |
| Termination： | Solder |
| Fastening Type： | Latch Lock/Eject Hooks |
| Features： | - |
| Contact Finish： | Gold |
| Contact Finish Thickness： | 10µin (0.25µm) |
| Color： | Black |
| Dynamic Catalog： | EHF Series |
| Other Names： | EHF12001LDSMSAM8213 |
