MCP42010-I/ST的详细信息
| Manufacturer： | Microchip |
|---|---|
| Product Category： | Digital Potentiometer ICs |
| RoHS： | Yes |
| Brand： | Microchip Technology |
| Resistance： | 10 kOhms |
| Number of POTs： | Dual |
| Taps per POT： | 256 |
| Digital Interface： | Serial |
| Operating Supply Voltage： | 2.7 V to 5.5 V |
| Supply Current： | 340 uA |
| Maximum Operating Temperature： | + 85 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | TSSOP-14 |
| Packaging： | Tube |
| Buffered Wiper： | Buffered |
| Description/Function： | 256 Step SPI 10k Ohm with SPI Interface |
| Minimum Operating Temperature： | - 40 C |
| Factory Pack Quantity： | 96 |
| Supply Voltage - Max： | 5.5 V |
| Supply Voltage - Min： | 2.7 V |
MCP42010-I/ST相关文档
- User Guides: Quick Guide to Microchip Development Tools
- Brochures: Analog & Interface Guide (Volume 2)
- Product Selection Tools: Analog & Interface Product Selector Guide
- Brochures: Signal Chain Design Guide
- Design Guides: Digital Potentiometer Design Guide
- Errata: MCP42010 Rev. A Silicon Errata
MCP42010-I/ST应用笔记
- AN219 - Comparing Digital Potentiometers to Mechanical Potentiometers
- AN746 - Interfacing Microchip's MCP41XXX/42XXX Digital Potentiometers to a PICmicro Microcontroller
- AN1316 - Using Digital Potentiometers for Programmable Amplifier Gain
- AN692 - Using a Digital Potentiometer to Optimize a Precision Single Supply Photo Detect
- AN691 - Optimizing the Digital Potentiometer in Precision Circuits
- AN737 - Using Digital Potentiometers to Design Low Pass Adjustable Filters
- AN1080 - Understanding Digital Potentiometers Resistor Variations
- DG9 - Analog Solutions for Automotive Applications Design Guide
- AN747 - Communicating with Daisy Chained MCP42XXX Digital Potentiometers
- AN757 - Interfacing Microchip's MCP41XXX and MCP42XXX Digital Potentiometers to Motorola?s 68HC12 Microcontroller
