ITT Cannon, LLC
MS3116F12-10PW的详细信息
| Datasheets： | |
|---|---|
| Mil-DTL 26482 (KPSE,KPT,MS)： | |
| Standard Package ： | 1 |
| Category： | Connectors, Interconnects |
| Family： | Circular Connectors |
| Series： | Military, MIL-DTL-26482 Series I, KPT |
| Packaging ： | Bulk |
| Connector Type： | Plug, Male Pins |
| Number of Positions： | 10 |
| Shell Size - Insert： | 12-10 |
| Shell Size, MIL： | - |
| Mounting Type： | Free Hanging (In-Line) |
| Termination： | Solder Cup |
| Fastening Type： | Bayonet Lock |
| Orientation： | W |
| Ingress Protection： | Environment Resistant |
| Shell Material, Finish： | Aluminum Alloy, Olive Drab Cadmium Plated |
| Contact Finish： | Gold |
| Features： | Strain Relief |
| Contact Finish Thickness： | 50µin (1.27µm) |
| Current Rating： | 7.5A |
| Voltage - Rated： | 600VAC, 850VDC |
| Operating Temperature： | -55°C ~ 125°C |
| Mating Products： | IMS3111J12-10SW-ND - CONN RCPT 10POS CBL MNT W/SCKTIMS3124F12-10SW-ND - CONN RCPT 10POS JAM NUT W/SCKTIMS3114F12-10SW-ND - CONN RCPT 10POS JAM NUT W/SCKTIMS3124P12-10SW-ND - CONN RCPT 10POS JAM NUT W/SCKTIMS3124E12-10SW-ND - CONN RCPT 10POS JAM NUT W/SCKTIMS3114P12-10SW-ND - CONN RCPT 10POS JAM NUT W/SCKTIMS3121F12-10SW-ND - CONN RCPT 10POS CBL MNT W/SCKTIMS3114E12-10SW-ND - CONN RCPT 10POS JAM NUT W/SCKTIMS3121P12-10SW-ND - CONN RCPT 10POS CBL MNT W/SCKTIMS3121E12-10SW-ND - CONN RCPT 10POS CBL MNT W/SCKTIMS3111F12-10SW-ND - CONN RCPT 10POS CBL MNT W/SCKTIMS3122E12-10SW-ND - CONN RCPT 10POS BOX MNT W/SCKTIMS3112E12-10SW-ND - CONN RCPT 10POS BOX MNT W/SCKT |
| Other Names： | IMS3116F12-10PWMS3116F12-10PWPEIMS3116F12-10PWPEI-ND |
