| 型号： | OPA340NA/3K |
| 厂商： |
 Texas Instruments |
| 标准： |   |
| 分类： | 半导体 ， 集成电路 - IC |
| 描述： | operational amplifiers - Op amps single-supply rail-to-rail |
| 报错 收藏 赞 | |
Datasheet下载地址
| 本地下载 >> 厂商下载2 >> 第三方平台下载 >> |
OPA340NA/3K的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Operational Amplifiers - Op Amps |
| RoHS： | Yes |
| Amplifier Type： | Low Offset Voltage Amplifier |
| Gain Bandwidth Product： | 5.5 MHz |
| Number of Channels： | 1 Channel |
| Common Mode Rejection Ratio - Min： | 70 dB |
| Input Offset Voltage： | 500 uV |
| Input Bias Current - Max： | 10 pA |
| Operating Supply Voltage： | 2.5 V to 5.5 V |
| Mounting Style： | SMD/SMT |
| Package / Case： | SOT-23-5 |
| Slew Rate： | 6 V/us |
| Shutdown： | No Shutdown |
| Maximum Operating Temperature： | + 85 C |
| Packaging： | Reel |
| Brand： | Texas Instruments |
| Input Referred Voltage Noise： | 25 nV |
| Minimum Operating Temperature： | - 40 C |
| Series： | OPA340 |
| Factory Pack Quantity： | 3000 |
| Supply Current： | 0.95 mA |
| Technology： | CMOS |
OPA340NA/3K相关文档
- PCN: Qualification of Vanguard Facility as an additional FAB site source for select OPA340xx and OPA2336xx
- PCN: Qualification of Vanguard Facility as an additional FAB site source for select OPA340xx and OPA2336xx devices in the 0.60UM process technology
- SPICE Model: OPA340 PSpice Model (Rev. A)
- TINA Reference Design: OPA340 TINA-TI Reference Design (Rev. C)
- Evaluation Kits: Capacitive Load Drive Verified Reference Design Using an Isolation Resistor
- SPICE Model: OPA340 TINA-TI Spice Model (Rev. B)
- PCN: Qualification of Vanguard Facility as an additional FAB site source for select OPA340xx and OPA2336xx devices in the 0.60UM process technology
OPA340NA/3K应用笔记
- Op Amp Performance Analysis
- Precision Absolute Value Circuits
- Shelf-Life Evaluation of Lead-Free Component Finishes
- A dual-polarity, bidirectional current-shunt monitor
- Optoelectronics Circuit Collection
- OPA340, OPA2340, OPA4340 EMI Immunity Performance (Rev. A)
- AB-174: Getting the Full Potential from your ADC (Rev. A)
- Single-Supply Operation of Operational Amplifiers
- Tuning in Amplifiers
- Q4 2008 Issue Analog Applications Journal
