PT06SE-10-6P(SR)的详细信息
| Datasheets： | |
|---|---|
| MIL-C-26482, Series 1： | |
| PT06SE(SR) Drawing： | |
| Product Photos： | |
| PT06SE10-6P(SR)： | |
| Product Training Modules： | |
| 26482 Series 1 Miniature Cylindrical Connector： | |
| Standard Package ： | 1 |
| Category： | Connectors, Interconnects |
| Family： | Circular Connectors |
| Series： | MIL-DTL-26482 Series I, PT |
| Packaging ： | Bulk |
| Connector Type： | Plug, Male Pins |
| Number of Positions： | 6 |
| Shell Size - Insert： | 10-6 |
| Shell Size, MIL： | - |
| Mounting Type： | Free Hanging (In-Line) |
| Termination： | Crimp |
| Fastening Type： | Bayonet Lock |
| Orientation： | N (Normal) |
| Ingress Protection： | Environment Resistant |
| Shell Material, Finish： | Aluminum, Olive Drab Cadmium Plated |
| Contact Finish： | Gold |
| Features： | Strain Relief |
| Contact Finish Thickness： | - |
| Current Rating： | 7.5A |
| Voltage - Rated： | 600VAC |
| Operating Temperature： | -55°C ~ 125°C |
| Dynamic Catalog： | MIL-DTL-26482 Series I, PT |
| Mating Products： | PT07E-10-6S-ND - CONN RCPT 6 POS JAM NUT W/SCKTPT01E-10-6S(SR)-ND - CONN RCPT 6 POS CBL MNT W/SCKTPT00E-10-6S(SR)-ND - CONN RCPT 6 POS WALL MNT W/SCKTPT02E-10-6S-ND - CONN RECEPT 6POS W/SOCKET SOLDERPT02SE10-6S-ND - CONN RECEPT 6POS W/SOCKETS CRIMP |
| Associated Product： | AT2020-ND - TOOL EXTRACTION 20 AWGATA1086-ND - TOOL INSERTIONATBX1-8107-20-ND - TOOL INSERTION PLIER METAL PT |
| Other Names： | PT06SE-10-6P(SR)-NDPT06SE10-6P(SR)PT06SE106PSR |
