MJF44H11G的详细信息
| Manufacturer： | ON Semiconductor |
|---|---|
| Product Category： | Transistors Bipolar - BJT |
| RoHS： | Yes |
| Brand： | ON Semiconductor |
| Configuration： | Single |
| Transistor Polarity： | NPN |
| Collector- Base Voltage VCBO： | 5 V |
| Collector- Emitter Voltage VCEO Max： | 80 V |
| Emitter- Base Voltage VEBO： | 5 V |
| Collector-Emitter Saturation Voltage： | 1 V |
| Maximum DC Collector Current： | 10 A |
| Gain Bandwidth Product fT： | 50 MHz |
| Maximum Operating Temperature： | + 150 C |
| Mounting Style： | Through Hole |
| Package / Case： | TO-220-3 FP |
| Continuous Collector Current： | 10 A |
| DC Collector/Base Gain hfe Min： | 60 |
| Maximum Power Dissipation： | 36 W |
| Minimum Operating Temperature： | - 55 C |
| Packaging： | Tube |
| Series： | MJF44H11 |
| Factory Pack Quantity： | 50 |
MJF44H11G相关文档
- Simulation Model: Spice3 Model
- Simulation Model: Saber Model
- Simulation Model: PSpice Model
- Package Drawing: TO-220 3 LEAD FULLPAK
- Simulation Model: Spice2 Model
- PCN: Initial Product / Process Change Notification
